Overview
This optical engine product is a "scientific-grade" high-performance lithography subsystem. Equipped with TI's ultra-high-resolution DLP chip (DLP991U UHD), it serves as a core component in fields such as high-end display, intelligent manufacturing, and cutting-edge scientific research.
Product Parameters
| Model | LTP‑dUHD‑Lx | |
| Platform | DLP991U | |
| Resolution | 4096×2176 | |
| Output Power | 0~50W | TBD |
| Printing Resolution | 2μm~50μm | |
| Image Size | 8.2mm×4.3mm ~ 204.8mm×108.8mm | Customizable |
| Contrast (ANSI) | >400:1 | ANSI |
| Uniformity | >90% | (Typical 13 point) |
| Distortion | <0.1% | |
| Working Distance | 40mm~162mm | |
| I/O Interface | USB3.01; Trigger in1; Trigger out*1 |
Product Features
8.9 million independent pixels, 4096 x 2176 ultra-high resolution, 5.4 μm micromirrors.
Ultra-high frame rate up to 12.4 kHz (binary).
Compatible with ultra-wide wavelength light sources ranging from 400 nm to 800 nm
Multi-projector tiling achievable with 25 μm ultra-high precision.
Application Scenarios
